■ Product introduction

Off-grid inverter designed and made for new energy power generation system, which is the core component of photovoltaic power generation system, can convert DC electrical energy into AC electric, mainly apply to PV power station, wind power station, wind, light, oil, storage complementary generating system and the field of household photovoltaic power system.

We use the new energy power generation with high inverter efficiency and advanced performance to provide absolute reliability for traffic inconvenience, harsh mountains, pasturing area, border defense and islands without electricity.

■ Function CharacteristicsIt is controlled by DSP chip with high performance made by TI.

- Good protection and alarm function for urgent issues such as output overload, output shot circuit, anti-counter connection, input over- voltage and low-voltage, over-temperature, etc.

- LED, LCD display (optional).

- Telecommunication (optional): RS232 communication interface can realize remote monitoring and control.

- Output pure sine wave, good dynamic response, small THD, high inverter efficiency, stable output voltage and excellent EMI.

- High reliability and efficiency, anti-vibration.
